Road safety requires working brake lights and turn signals to help keep other motorists aware of your intentions as you drive. These safety factors become even more important when you're towing a caravan or trailer, since you are effectively increasing the "length" of your vehicle and decreasing its maneuverability. The caravan is likely to block your vehicle's brake lights and turn signals, trailer lights help ensure that safety isn't compromised when you tow.So in order to be safe on the road one needs to make sure that the electrical wiring circuits of your vehicle and trailer or caravan works one hundred percent and to help you with this task, you need a trailer plug tester.

With this trailer tester you can test the vehicle, caravan and trailer electrical circuits all by yourself. You don't need to have someone helping you. This trailer tester does all the hard work for you. Testing, repairing and solving problems has become much easier using this trailer tester. No more spending hours to find and repair electrical faults.

This trailer tester is specifically designed to help motor mechanics, auto electricians, camping, trucking and trailer or caravan renting businesses to test/trace faults on there trailers/carvans wiring as quickly as posible. For a normal person owning trailers or caravan this trailer wire tester will also be a handy tool which will make testing easy, especially to test your trailer or caravan roadworthy condition for a holiday trip. It is user friendly and it comes with a fully explained guide on how to use it.

Last but not least you and your business will look even more professional as testing can be done right in front of your customer and it only takes a minute to run through all the trailer’s lights circuits. Very Important Feature, you can even test the customers car’s trailer socket connections and lights on the spot if there is a dispute that the trailer’s wiring is wrong connected. Best of all is this tester is absolute portable and mobile, its new size is almost as big as a notebook!! Ever thing is in one case.

Please note on request this tester can be modify to any country wiring standard.

NEW DESIGN!!!! MORE PORTABLE

New Model

Trailer Tester New Model

Benefits:

Stronger, smaller and specifically designed and built for Car Agents and Mechanical Workshops.

Dimensions:

LENGTH: 240 mm

WIDTH: 190 mm

HEIGHT (BOX): 90mm

HEIGHT TO TOP OF TOW PLUG 150 mm

WEIGHT: APPROXIMATELY 5 KG

Product Features:

• Test trailer, caravan and motorcar wiring circuit standard (S A B S)

• Test tail light wiring and light bulbs of trailer, caravan & motorcar

• Test stop light wiring and light bulbs of trailer, caravan & motorcar

• Test left hand indicator wiring and light bulbs of trailer, caravan & motorcar

• Test right hand indicator wiring and light bulbs of trailer, caravan & motorcar

• Test earth (negative) fault on motorcar

• Test auxiliary wire connection on trailer, caravan & motorcar

• Test tail light switch of motorcar

• Tests stop light sensor/ switch of motorcar

• Test left and right hand indicator switch of motorcar

• Test hazards switch of motorcar

• 12 V Output terminals when required

• Free email support

Product Includes:

1. Main Tester 12 V

2. Mini Fully Automatic 12 V Charger

3. Rechargeable Battery 12 V / 7 AH

4. Eight Meter Power Cable

5. Two 7.5 AMP Fuses

6. S A B S Wiring Diagram

7. Fully Explained User Manual

To download the sales page of this tester - click here

Older Model

Trailer Tester

Trailer Tester Features:

• Test trailer, caravan and motorcar wiring circuit standard (S A B S)

• Test tail light wiring and light bulbs of trailer, caravan & motorcar

• Test stop light wiring and light bulbs of trailer, caravan & motorcar

• Test left hand indicator wiring and light bulbs of trailer, caravan & motorcar

• Test right hand indicator wiring and light bulbs of trailer, caravan & motorcar

• Test earth (negative) fault on motorcar

• Test auxiliary wire connection on trailer, caravan & motorcar

• Test tail light switch of motorcar

• Tests stop light sensor/ switch of motorcar

• Test left and right hand indicator switch of motorcar

• Test hazards switch of motorcar

• 12 V Output terminals when required

• Free email support

Product Includes:

1. Main Tester 12 V / 15 A

2. Mini Fully Automatic 12 V Charger

3. Rechargeable Battery 12 V / 7 AH

4. Eight Meter Power Cable

5. Two 15 AMP fuses

6. S A B S Wiring Diagram

7. User Manual On CD

To download the sales page of this tester - click here

Info: How To Wire Your Trailer Wiring

Important: Before beginning installation, check your vehicle's owner's manual and/or the service manual to familiarize yourself with the wiring of the rear lights on your vehicle as there may be slight difference among vehicles.

Follow the instructions that comes with your trailer tester kit and connect the wiring as according to the SABS standard.

Socket and plug wiring instruction

Use 7 core wire (8mm gauge) Socket South Africa.

1) Yellow - left Indicators

2) Blue - Spare/Fridge

3) White - Earth

4) Green - Right Indicators

5) Brown - Tail Lamps and number plate

6) Red - Stop Lamps

7) Black - Tail lamps and number plate

Note. Pins 5 and 7 are normally bridged.

The Earth. (No 3 – white)

The tow hitch of the van or trailer must be on the tow bar of the vehicle so as to create an efficient earth connection. Terminal no 3 (white) has a wire connected at the socket so as to ensure that the trailer/caravan is also connected, and this white wire must be connected to the chassis of the towing vehicle as well.

The Spare/Fridge. (No 2 – Blue) is used to connect the fridge. A 15 amp fuse connector should be connected as a safety precaution. It is recommended that if you do not feel happy doing it yourself it is then better get a tow bar/trailer specialist to undertake this operation.
